Coordination resolved in the model, not on site. Architectural, structural and MEP BIM, from scan to fabrication-ready content.
More than 150,000 tons of steel detailed. Shop and erection drawings, connection design and take-offs your fabricator builds from.
Coordinated shop drawings every trade can build from, from MEP and fire protection to facades and millwork.
See it right before it’s built. Photoreal renderings that win approvals and keep design intent intact from concept to marketing.
Design intent preserved on every sheet. Permit- and build-ready drawing sets, plus conversion and markup of existing drawings.
Production-ready from the first run. Precision 3D CAD for aviation, marine and automotive programs, where tolerances leave no margin.
For architects
Every design error caught in the model is one your client never pays for on site. Drawings go out right, and your margin stays as planned.
Confidential. Reviewed by a senior engineer.
Before anything is built
Risk is visible in the model long before it reaches the site or the shop floor. What decides the outcome is who finds it first.
01Margin
Margin is rarely lost at once. It leaks through coordination gaps, loose handoffs and unchecked assumptions.
We put a dollar figure on every gap and close it in the model, long before it becomes a change order.
02Schedule
Programs rarely slip for lack of effort. They slip when one early decision never reaches every trade.
We work as your extended team, overlapping 75% of your working day, so model, drawings and site align.
03Accuracy
From steel connections to aerospace parts, accuracy is decided in the model, before anything is cut or welded.
Every connection and tolerance is proven before release, so parts arrive production-ready, first time.
Expertise
Twelve services across construction, fabrication and manufacturing, delivered to one standard.
How We Work
Five steps, one result: the margin you keep. For a $1B firm, a 2% leak is $20M lost every year, and each step closes one. See the full process
A Margin Assessment shows, in dollars, what your operations lose.
Your leak, in dollars.
Priorities, standards and team agreed in writing before work starts.
Scope locked early.
All trades coordinated; clashes fixed on screen, not on site.
No rework on site.
A senior engineer reviews every model and drawing before release.
Right the first time.
Savings measured and carried into your next program.
Margin you keep.
A two-minute assessment shows where your program is exposed, and what can still be recovered.
Industries
One discipline in every industry: resolved in the model before the field or shop floor.
Start a conversation
For over 20 years, one standard has guided every model, drawing and component. Let’s talk about where your programs are losing margin.
Or write to info@bimgraphix.com
